G12C75M90H44

⌀ 12 inch NEO

Nom. Impedance: 8Ω(LF) 8Ω(HF)

Voice Coil ⌀: 75mm(LF) 90mm(MD) 44mm(HF)

Continuous Program: 1000W(LF) 300W(MD) 80W(HF)

Sensitivity: 95dB(LF) 104dB(MD) 105dB(HF)


Availability:



Inquire Add to Basket

Nominal Diameter

12'' / 320 mm

Power Handling Nominal (AES)

500W(LF) 150W(MD) 40W (HF)

Continuous Program

1000W(LF) 300W(MD)160W(HF)

Minimum Impedance

5.6Ω(LF) 6Ω(MD)

6Ω(HF)

Voice Coil Diameter

75mm(LF) 90mm(MD) 44mm(HF)

Magnet Material

Neodymium

Sensitivity 1W/1m

95dB(LF) 104dB(MD) 105dB(HF)

Frequency Range

48-20K Hz

Winding Material

Aluminum(MD&HF) Copper(LF)

Former Material(LF)

Glass Fiber

Diaphragm Material (MD&HF）

Polyimide

Recommended Crossover

500 Hz(MD） 6K Hz(HF)
