G10C75H65XH

⌀ 10 inch NEO
Nom. Impedance: 8Ω(LF) 8Ω(HF)
Voice Coil ⌀: 75mm(LF) 65mm(HF)
Continuous Program: 800W(LF) 160W(HF)
Sensitivity: 97dB(LF) 105dB(HF)


Availability:



Inquire Add to Basket

Nominal Diameter

10'' / 260 mm

Power Handling Nominal(AES)

400W (LF) 80W (HF)

Continuous Program

800W(LF) 160W(HF)

Minimum Impedance

5.3Ω(LF) 6Ω (HF)

Voice Coil Diameter

75mm(LF) 65mm(HF)

Magnet Material

Neodymium

Sensitivity 1W/1m

97 dB(LF) 105 dB(HF)

Frequency Range

65 - 18K Hz

Winding Material (LF&HF）

Aluminum

Former Material(LF)

Glass Fiber

Diaphragm Material

Titanium

Recommended Crossover

1.5K Hz
